| Broj dijela | LM230WF4-TLA1 |
| Marka | LG Display |
| Veličina | 23.0 |
| Primjena | DMPC |
| Rezolucija | 1920×1080 |
| Sastav | LCM |
| Svjetlina | 400 |
| CR | 1000:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | LVDS |
| marka panela | LG Display |
| panelni model | LM230WF4-TLA1 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 23.0 inch |
| rezolucija | 1920(RGB)×1080 , FHD |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 509.184×286.416 mm |
| obris | 533.2×312 mm |
| površinski | Antiglare, Hard coating (3H) |
| svjetlina | 400 cd/m² (Typ.) |
| omjer kontrasta | 1000:1 (Typ.) |
| boje prikaza | 16.7M (6-bit + Hi-FRC), CIE193172% |
| vrijeme odziva | 1/4 (Typ.)(Tr/Td); 3 (Typ.)(G to G) |
| kut gledanja | 85/85/75/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 120Hz |
| tip svjetiljke | 4 pcsCCFLWithout Driver |
| signalno sučelje | LVDS (4 ch, 8-bit), 92 pins |
| ulazni napon | 12.0V (Typ.) |
| primjena | DMPC |
| LM230WF2-SLA2 | LG Display | 23.0 | 1920×1080 |
| LM230WF3-SLB1 | LG Display | 23.0 | 1920×1080 |
| LM230WF3-SLB2 | LG Display | 23.0 | 1920×1080 |
| LM230WF3-SLD1 | LG Display | 23.0 | 1920×1080 |
| LM230WF3-SLK1 | LG Display | 23.0 | 1920×1080 |
| LM230WF3-SSA1 | LG Display | 23.0 | 1920×1080 |
| LM230WF5-TLB1 | LG Display | 23.0 | 1920×1080 |
| LM230WF5-TLD1 | LG Display | 23.0 | 1920×1080 |
| LM230WF5-TLF4 | LG Display | 23.0 | 1920×1080 |
| LM230WF5-TLG1 | LG Display | 23.0 | 1920×1080 |
| HSD170MGW1-A00 | HannStar | 17.0 | 1440×900 |
| LM185WH2-TLA1 | LG Display | 18.5 | 1366×768 |
| LM215WF1-TLE1 | LG Display | 21.5 | 1920×1080 |
| LTM190E4-L02 | Samsung | 19.0 | 1280×1024 |
| LTM240CL01 | Samsung | 24.0 | 1920×1200 |
| LTM240CT04 | Samsung | 24.0 | 1920×1200 |
| M270H3-L01 | Innolux | 27.0 | 1920×1080 |
| NL10276AC30-04R | NLT | 15.0 | 1024×768 |
| NL128102BC29-01C | NLT | 19.0 | 1280×1024 |
| TMS156WX1-01TB | Tianma | 15.6 | 1366×768 |
