| Broj dijela | LC470EUH-PEF1 |
| Marka | LG Display |
| Veličina | 47 |
| Primjena | LCTV |
| Rezolucija | 1920×1080 |
| Sastav | LCM |
| Svjetlina | 400 |
| CR | 1600:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | EPI |
| marka panela | LG Display |
| panelni model | LC470EUH-PEF1 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 47 inch |
| rezolucija | 1920(RGB)×1080 , FHD |
| način prikaza | S-IPS, Normally Black, Transmissive |
| aktivno područje | 1039.68×584.82 mm |
| obris | 1059.48×616.21 mm |
| površinski | Antiglare (Haze 1%), Hard coating (2H) |
| svjetlina | 400 cd/m² (Typ.) |
| omjer kontrasta | 1600:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193172% |
| vrijeme odziva | 8/10 (Typ.)(Tr/Td) |
| kut gledanja | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| frekvencija | 120Hz |
| tip svjetiljke | WLEDWithout Driver |
| signalno sučelje | EPI, 100 pins |
| ulazni napon | 12.0V (Typ.) |
| primjena | LCTV |
