| Broj dijela | LC420WX7-SLA1 |
| Marka | LG Display |
| Veličina | 42 |
| Primjena | LCTV |
| Rezolucija | 1366×768 |
| Sastav | LCM |
| Svjetlina | 500 |
| CR | 1000:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | EEFL |
| Sučelje | LVDS |
| marka panela | LG.Philips LCD |
| panelni model | LC420WX7-SLA1 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 42 inch |
| rezolucija | 1366(RGB)×768 , WXGA |
| način prikaza | S-IPS, Normally Black, Transmissive |
| aktivno područje | 930.25×523.01 mm |
| obris | 983×576 mm |
| površinski | Antiglare (Haze 13%), Hard coating (3H) |
| svjetlina | 500 cd/m² (Typ.) |
| omjer kontrasta | 1000:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193173% |
| vrijeme odziva | 10 (Typ.)(Tr+Td); 5 (Typ.)(G to G) |
| kut gledanja | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | EEFLEmbedded (Inverter) |
| signalno sučelje | LVDS (1 ch, 8-bit), 30 pins |
| ulazni napon | 12.0V (Typ.) |
| primjena | LCTV |
