| Broj dijela | KG057QV1CA-G020W |
| Marka | Kyocera |
| Veličina | 5.7 |
| Primjena | IA |
| Rezolucija | 320×240 |
| Sastav | LCM |
| Svjetlina | 260 |
| CR | 4:1 |
| Boje | Monochrome |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | Parallel Data |
| marka panela | Kyocera |
| panelni model | KG057QV1CA-G020W |
| vrsta panela | STN-LCD , LCM |
| veličina ploče | 5.7 inch |
| rezolucija | 320×240 , QVGA |
| način prikaza | STN, Blue mode (Negative), Transmissive |
| aktivno područje | 115.18×86.38 mm |
| obris | 144×104.8×13.2 mm |
| površinski | Glare (Haze 0%) |
| svjetlina | 260 cd/m² (Typ.) |
| omjer kontrasta | 4:1 (Typ.) |
| boje prikaza | Monochrome |
| vrijeme odziva | 380/120 (Typ.)(Tr/Td) |
| kut gledanja | 45/45/20/40 (Typ.)(CR≥2)(L/R/U/D) |
| frekvencija | 75Hz |
| tip svjetiljke | 1 pcsCCFLOptional |
| signalno sučelje | Parallel Data (4-bit), 20 pins |
| ulazni napon | 3.3/5.0V (Typ.)(VDD) |
| primjena | IA |
