| Broj dijela | HX104X02-100 |
| Marka | HYDIS |
| Veličina | 10.4 |
| Primjena | PAD |
| Rezolucija | 1024×768 |
| Sastav | LCM |
| Svjetlina | 340 |
| CR | 600:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | HYDIS |
| panelni model | HX104X02-100 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 10.4 inch |
| rezolucija | 1024(RGB)×768 , XGA |
| način prikaza | AFFS+, Normally Black, Transmissive |
| aktivno područje | 210.4×157.8 mm |
| obris | 238.6×173.2×6.8 mm |
| površinski | Antiglare, Antireflection |
| svjetlina | 340 cd/m² (Typ.) |
| omjer kontrasta | 600:1 (Typ.) |
| boje prikaza | 262K (6-bit), CIE193140% |
| vrijeme odziva | 36 (Typ.)(Tr+Td) |
| kut gledanja | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 7S6PWLEDEmbedded (LED Driver) |
| signalno sučelje | LVDS (1 ch, 6-bit), 30 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | PAD |
