| Broj dijela | HK185LEDM-CH25H |
| Marka | Other |
| Veličina | 18.5 |
| Primjena | LCTV |
| Rezolucija | 1366×768 |
| Sastav | LCM |
| Svjetlina | 220 |
| CR | 3000:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | No Brand |
| panelni model | HK185LEDM-CH25H |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 18.5 inch |
| rezolucija | 1366(RGB)×768 , WXGA |
| način prikaza | Super MVA, Normally Black, Transmissive |
| aktivno područje | 409.8×230.4 mm |
| obris | 430.37×254.6×11.5 mm |
| površinski | Antiglare (Haze 1%) |
| svjetlina | 220 cd/m² (Typ.) |
| omjer kontrasta | 3000:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193172% |
| vrijeme odziva | 9 (Typ.)(G to G) |
| kut gledanja | 89/89/89/89 (Typ.)(CR≥20)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | WLEDWithout Driver |
| signalno sučelje | LVDS (1 ch, 8-bit), 30 pins |
| ulazni napon | 5.0V (Typ.) |
| primjena | LCTV |
| CLAA185WA02 | CPT | 18.5 | 1366×768 |
| HK185LEDM-CH25H | Other | 18.5 | 1366×768 |
| LC185EXE-TEA1 | LG Display | 18.5 | 1366×768 |
| LM185TT4A | PANDA | 18.5 | 1366×768 |
| LM185WH2-TLA1 | LG Display | 18.5 | 1366×768 |
| M185B1-L02 | Innolux | 18.5 | 1366×768 |
| M185BGE-L22 | Innolux | 18.5 | 1366×768 |
| M185XW01 V5 | AUO | 18.5 | 1366×768 |
| MT185WHM-N20 | BOE | 18.5 | 1366×768 |
| V185B1-LE1 | Innolux | 18.5 | 1366×768 |
| LC370WUG-SCA2 | LG Display | 37 | 1920×1080 |
| LC420WUN-SCB1 | LG Display | 42 | 1920×1080 |
| LC490EGE-FHM1 | LG Display | 49 | 3840×2160 |
| LC490EUE-FHM1 | LG Display | 49 | 1920×1080 |
| LC600DUF-FGP2 | LG Display | 60 | 1920×1080 |
| LTY400HM10 | Samsung | 40 | 1920×1080 |
| LTY520HE06 | Samsung | 52 | 1920×1080 |
| T460HVN08.2 CELL | AUO | 46 | 1920×1080 |
| V260B1-L01 | Innolux | 26.0 | 1366×768 |
| V500HJ1-L01 | Innolux | 50 | 1920×1080 |
