| Broj dijela | DLC0430LZG-T |
| Marka | Other |
| Veličina | 4.3 |
| Primjena | PND |
| Rezolucija | 480×272 |
| Sastav | LCM |
| Svjetlina | 280 |
| CR | 550:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | DLC |
| panelni model | DLC0430LZG-T |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 4.3 inch |
| rezolucija | 480(RGB)×272 , WQVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 95.04×53.856 mm |
| obris | 105.5×67.2×4.3 mm |
| površinski | Hard coating (3H) |
| svjetlina | 280 cd/m² (Typ.) |
| omjer kontrasta | 550:1 (Typ.) |
| boje prikaza | 16.7M (6-bit + Hi-FRC), CIE193150% |
| vrijeme odziva | 20 (Typ.)(Tr+Td) |
| kut gledanja | 70/70/70/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 5S2PWLEDWithout Driver |
| signalno sučelje | Parallel RGB (1 ch, 8-bit), 40 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | PND |
