| Broj dijela | CLAA185WA04 |
| Marka | CPT |
| Veličina | 18.5 |
| Primjena | DMPC |
| Rezolucija | 1366×768 |
| Sastav | LCM |
| Svjetlina | 250 |
| CR | 1000:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | CPT |
| panelni model | CLAA185WA04 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 18.5 inch |
| rezolucija | 1366(RGB)×768 , WXGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 409.8×230.4 mm |
| obris | 430.37×254.6×11.5 mm |
| površinski | Antiglare, Hard coating (3H) |
| svjetlina | 250 cd/m² (Typ.) |
| omjer kontrasta | 1000:1 (Typ.) |
| boje prikaza | 16.7M (6-bit + Hi-FRC) |
| vrijeme odziva | 5 (Typ.)(Tr+Td) |
| kut gledanja | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | WLEDWithout Driver |
| signalno sučelje | LVDS (1 ch, 8-bit), 30 pins |
| ulazni napon | 5.0V (Typ.) |
| primjena | DMPC |
| CLAA101FP01 | CPT | 10.1 | 1920×1200 |
| CLAA101FP01 XG | CPT | 10.1 | 1920×1200 |
| CLAA101WB03 | CPT | 10.1 | 1366×768 |
| CLAA102NA2CCN | CPT | 10.2 | 1024×600 |
| CLAA104XA01CW | CPT | 10.4 | 1024×768 |
| CLAA104XA02CW | CPT | 10.4 | 1024×768 |
| CLAA150XP01Q V2 | CPT | 15.0 | 1024×768 |
| CLAA156WA07A | CPT | 15.6 | 1366×768 |
| CLAA156WA11A | CPT | 15.6 | 1366×768 |
| CLAA170EA10 | CPT | 17.0 | 1280×1024 |
| CLAA150XP01Q V2 | CPT | 15.0 | 1024×768 |
| HT15X15-D01 | HYDIS | 15.0 | 1024×768 |
| LM190E08-TLL3 | LG Display | 19.0 | 1280×1024 |
| LM215WF8-TLA1 | LG Display | 21.5 | 1920×1080 |
| LQ150X1LCD3 | SHARP | 15.0 | 1024×768 |
| M170EG01 VF | AUO | 17.0 | 1280×1024 |
| M195RTN01.0 | AUO | 19.5 | 1600×900 |
| M236H3-LA3 | Innolux | 23.6 | 1920×1080 |
| M236HJK-L5B | Innolux | 23.6 | 1920×1080 |
| TMS156WX1-01TB | Tianma | 15.6 | 1366×768 |
