| Broj dijela | CLAA088WA01XN |
| Marka | CPT |
| Veličina | 8.8 |
| Primjena | CNS |
| Rezolucija | 1280×480 |
| Sastav | LCM |
| Svjetlina | 500 |
| CR | 1000:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | CPT |
| panelni model | CLAA088WA01XN |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 8.8 inch |
| rezolucija | 1280(RGB)×480 , DVGA |
| način prikaza | HFFS, Normally Black, Transmissive |
| aktivno područje | 209.28×78.48 mm |
| obris | 229.6×97.3×6.3 mm |
| površinski | Antiglare (Haze 25%) |
| svjetlina | 500 cd/m² (Typ.) |
| omjer kontrasta | 1000:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193170% |
| vrijeme odziva | 25 (Typ.)(Tr+Td) |
| kut gledanja | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 3S14PWLEDWithout Driver |
| signalno sučelje | LVDS (1 ch, 8-bit), 60 pins |
| ulazni napon | 3.3/13.0/20/-6.0V (Typ.)(DVDD/AVDD/IGH/IGL) |
| primjena | CNS |
