| Broj dijela | AX080E002B |
| Marka | KOE |
| Veličina | 31.5 |
| Primjena | LCTV |
| Rezolucija | 1366×768 |
| Sastav | LCM |
| Svjetlina | 500 |
| CR | 950:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | EEFL |
| Sučelje | LVDS |
| marka panela | IPS Alpha |
| panelni model | AX080E002B |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 31.5 inch |
| rezolucija | 1366(RGB)×768 , WXGA |
| način prikaza | IPS-Pro, Normally Black, Transmissive |
| aktivno područje | 697.685×392.256 mm |
| obris | 760×450 mm |
| površinski | Antiglare |
| svjetlina | 500 cd/m² (Typ.) |
| omjer kontrasta | 950:1 (Typ.) |
| boje prikaza | 16.7M (8-bit) |
| vrijeme odziva | 8/6 (Typ.)(Tr/Td); 17 (Typ.)(MPRT) |
| kut gledanja | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 16 pcsEEFLEmbedded (Inverter) |
| signalno sučelje | LVDS (1 ch, 8-bit), 41 pins |
| ulazni napon | 12.0V (Typ.) |
| primjena | LCTV |
