| Broj dijela | AA050ME01 |
| Marka | Mitsubishi |
| Veličina | 5.0 |
| Primjena | IA |
| Rezolucija | 800×480 |
| Sastav | LCM |
| Svjetlina | 420 |
| CR | 450:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | Mitsubishi |
| panelni model | AA050ME01 1 Compatible model |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 5.0 inch |
| rezolucija | 800(RGB)×480 , WVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 108×64.8 mm |
| obris | 118.5×77.8×5.4 mm |
| površinski | Clear, Hard coating (2H) |
| svjetlina | 420 cd/m² (Typ.) |
| omjer kontrasta | 450:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193150% |
| vrijeme odziva | 5/20 (Typ.)(Tr/Td) |
| kut gledanja | 65/65/65/45 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 2 stringsWLEDWithout Driver |
| signalno sučelje | CMOS (1 ch, 8-bit), 45 pins |
| ulazni napon | 3.3/5.0V (Typ.)(VCC/AVDD) |
| primjena | IA |
